RTD14005F
Manufacturer:
TE Connectivity
Mfr.Part #:
RTD14005F
Datasheet:
Description:
Power Relays Through Hole 80 mA 62 Ω 5 V General Purpose
| Parameter | Value |
|---|---|
| Length | 29.0068 mm |
| Width | 12.7 mm |
| Termination | Plug |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Voltage Rating (AC) | 380 V |
| Number of Pins | 8 |
| Height | 15.7 mm |
| Packaging | Tube |
| Lead Free | Lead Free |
| RoHS | Compliant |
| REACH SVHC | Unknown |
| Weight | 14.004664 g |
| Contact Material(Contact Finish) | Silver Nickel (AgNi) |
| Current Rating | 16 A |
| Approvals | CSA, VDE, cULus |
| Dropout Voltage | 500 mV |
| Lifecycle Status | Production (Last Updated: 4 days ago) |
| ELV | Compliant |
| Throw Configuration | SPDT |
| Max Voltage Rating (AC) | 400 V |
| Coil Voltage (DC) | 5 V |
| Coil Current | 80 mA |
| Coil Type | Non-Latching |
| Coil Resistance | 62 Ω |
| Relay Type | General Purpose |
| Operate Time | 8 ms |
| Release Time | 6 ms |
| Contact Current Rating | 16 A |
| power consumption | 400 mW |
| Termination Style | PC Pin |
| Switching Voltage | 400 V |
| Coil Power | 500 mW |
| Coil Voltage (AC) | 5 V |
| Contact Voltage Rating (AC) | 250 V |
| Schedule B | 8536490075 |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 4 days ago) |
| Must Operate Voltage | 3.5 V |
| Must Release Voltage | 500 mV |
Stock: 1752
Distributors
pcbx
pcbxUnit Price$3.28550
Ext.Price$3.28550
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $3.28550 | $3.28550 |
| 10 | $3.09979 | $30.99790 |
| 25 | $2.92458 | $73.11450 |
| 50 | $2.75927 | $137.96350 |
| 100 | $2.60326 | $260.32600 |
| 300 | $2.50123 | $750.36900 |
| 500 | $2.40320 | $1201.60000 |
| 1000 | $2.32199 | $2321.99000 |
